EdgeFlow Platform

Lightweight, visual IoT automation platform for Raspberry Pi and edge devices

Website · Features · Quick Start · Tech Stack · Build Profiles · Contributing

---

About

EdgeFlow is a node-based automation platform that lets you build IoT workflows visually. Connect sensors, process data, trigger actions, and monitor everything from a single dashboard — no cloud required.

• Single binary — deploy one Go binary + static frontend, no runtime dependencies
• Built for constrained devices — runs on a Raspberry Pi Zero with ~50 MB RAM
• 150+ built-in nodes — GPIO, MQTT, Modbus, databases, AI, and more out of the box
• Hardware-first — native GPIO support for Pi 4/5 via Linux character device, not memory-mapped hacks

Think Node-RED, but lighter, faster, and purpose-built for edge devices.

Features

Visual Flow Editor

• Drag-and-drop node canvas with 150+ pre-built node types
• Real-time execution tracing and debug panel
• Sub-flow support for reusable logic
• Built-in terminal, logs, and system monitoring panels

Hardware Integration

• Raspberry Pi 4/5 GPIO via Linux character device (gpiocdev)
• I2C sensors (BME280, BMP280, BH1750, AHT20, ADS1015, and more)
• PIR motion, HC-SR04 ultrasonic, relay, LED, button
• Software PWM and edge detection

Industrial & Wireless Protocols

• MQTT, Modbus TCP/RTU, OPC-UA, BACnet, CAN Bus, PROFINET
• BLE, Zigbee, Z-Wave, LoRa, NFC, RFID, RF433, IR

Integrations

• AI/LLM: OpenAI, Anthropic, Ollama
• Databases: SQLite, PostgreSQL, MySQL, MongoDB, Redis, InfluxDB
• Cloud Storage: AWS S3, Google Drive, Dropbox, OneDrive
• Messaging: Email, Telegram, Slack, Discord
• HTTP webhooks and REST APIs

Monitoring & Debugging

• CPU, memory, disk, temperature, network speed
• GPIO state visualization
• Execution history with structured logs
• Web-based interactive terminal

Quick Start

Prerequisites

• Go 1.24+
• Node.js 18+
• Git

Run Locally

# Clone
git clone https://github.com/EdgxCloud/EdgeFlow.git
cd EdgeFlow

# Build & run backend
make run

# In another terminal — build frontend
cd web
npm install
npm run dev

Open http://localhost:5173 (dev) or http://localhost:8080 (production build).

Docker

docker compose up -d

Raspberry Pi

# Build for ARM64
make build-pi-standard

# Install as service
sudo cp deploy/edgeflow-backend.service /etc/systemd/system/
sudo systemctl enable --now edgeflow-backend

Tech Stack

Layer	Technology
Backend	Go 1.24, Fiber v2, Zap logging
Frontend	React 18, TypeScript, Vite, Tailwind CSS
Flow Canvas	React Flow (@xyflow/react)
Code Editor	Monaco Editor
UI Components	Radix UI
State	Zustand
Hardware	go-gpiocdev (Linux character device)
Protocols	MQTT (Paho), Modbus, OPC-UA
Databases	SQLite, PostgreSQL, MySQL, MongoDB, Redis, InfluxDB
Auth	JWT, API key

Node Categories

150+ nodes across 10 categories:

Category	Count	Examples
Core	25+	inject, debug, function, switch, template, delay, trigger, filter
GPIO	15+	digital in/out, PWM, PIR, HC-SR04, DHT, BMP280, servo
Network	10+	HTTP request, webhook, TCP, UDP, FTP, CSV/JSON parser
Database	6	SQLite, PostgreSQL, MySQL, MongoDB, Redis, InfluxDB
Messaging	4	Email, Telegram, Slack, Discord
AI/ML	3	OpenAI, Anthropic, Ollama
Industrial	5	Modbus TCP/RTU, OPC-UA, BACnet, CAN Bus, PROFINET
Wireless	10+	BLE, Zigbee, Z-Wave, LoRa, NFC, RFID, RF433, IR
Dashboard	12	Chart, gauge, button, slider, switch, table, form, template
Cloud Storage	5	AWS S3, Google Drive, Dropbox, OneDrive, SFTP

Build Profiles

Three build profiles optimized for different hardware:

Profile	Target	Binary Size	RAM Usage
Minimal	Pi Zero, BeagleBone	~10 MB	~50 MB
Standard	Pi 3, Orange Pi	~20 MB	~200 MB
Full	Pi 4/5, Jetson	~35 MB	~400 MB

make build PROFILE=minimal    # Pi Zero / constrained devices
make build PROFILE=standard   # Pi 3/4 / general use
make build PROFILE=full       # Pi 4/5 / all features

Configuration

Copy .env.example to .env and configure:

EDGEFLOW_SERVER_HOST=0.0.0.0
EDGEFLOW_SERVER_PORT=8080
EDGEFLOW_DATABASE_TYPE=sqlite
EDGEFLOW_DATABASE_PATH=./data/edgeflow.db
EDGEFLOW_LOGGER_LEVEL=info

Project Structure

EdgeFlow Platform
├── cmd/edgeflow/          # Application entry point
├── internal/
│   ├── api/               # REST API handlers (Fiber)
│   ├── engine/            # Flow execution engine & scheduler
│   ├── hal/               # Hardware Abstraction Layer (GPIO, I2C, SPI, Serial)
│   ├── node/              # Node registry & message framework
│   ├── storage/           # File, SQLite, Redis backends
│   ├── websocket/         # Real-time WebSocket hub
│   ├── resources/         # System monitoring (CPU, memory, temp)
│   ├── security/          # JWT & API key auth
│   ├── logger/            # Structured logging (Zap)
│   ├── plugin/            # Plugin system
│   └── subflow/           # Nested flow support
├── pkg/nodes/
│   ├── core/              # Inject, debug, function, switch, template, delay...
│   ├── gpio/              # PIR, HC-SR04, LED, relay, button, sensors
│   ├── network/           # HTTP request/webhook, FTP, CSV/JSON parsers
│   ├── database/          # SQLite, PostgreSQL, MySQL, MongoDB, Redis, InfluxDB
│   ├── messaging/         # Email, Telegram, Slack, Discord
│   ├── ai/                # OpenAI, Anthropic, Ollama
│   ├── industrial/        # Modbus, OPC-UA, BACnet, CAN Bus, PROFINET
│   ├── wireless/          # BLE, Zigbee, Z-Wave, LoRa, NFC, RF433, IR
│   ├── storage/           # S3, Google Drive, Dropbox, OneDrive, SFTP
│   └── dashboard/         # UI widgets (chart, gauge, table, form, button...)
├── web/                   # React + TypeScript frontend (Vite)
├── configs/               # Default configuration
├── deploy/                # Systemd service files
└── docker-compose.yml

REST API

Base URL: /api/v1

Endpoint	Method	Description
/flows	GET, POST	List / create flows
/flows/:id	GET, PUT, DELETE	Get / update / delete flow
/flows/:id/start	POST	Start flow execution
/flows/:id/stop	POST	Stop flow
/flows/:id/nodes	GET, POST	List / add nodes
/flows/:id/connections	GET, POST	List / add connections
/node-types	GET	List all 150+ node types
/executions	GET	Execution history
/resources/stats	GET	CPU, memory, disk stats
/system/info	GET	System info, temperature, uptime
/modules	GET	Installed modules
/modules/install	POST	Install a module
/health	GET	Health check

WebSocket: /ws (logs, debug, execution events), /ws/terminal (interactive shell)

Roadmap

• Plugin marketplace
• Flow versioning and rollback
• Multi-device orchestration
• Mobile companion app
• Visual rule engine for complex conditions

See the open issues for a full list of proposed features and known issues.

Contributing

Contributions are welcome! Whether it's bug reports, feature requests, or pull requests — all contributions help make EdgeFlow better.

1. Fork the repository
2. Create your feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

Community

• GitHub Issues — Bug reports and feature requests
• GitHub Discussions — Questions and ideas

License

Distributed under the Apache License 2.0. See LICENSE for more information.
