Aquiles-ai: Demo Chatbot

A demo chatbot that uses Aquiles-RAG as a Retrieval-Augmented Generation (RAG) server to index documents and answer queries by combining semantic search with GPT-4.1.

📂 Project Structure

AI-Server/
├── context.py         # RAG logic: query optimization, indexing, and response streaming
├── main.py            # FastAPI server: HTTP routes and WebSocket endpoint
├── utils.py           # libSQL/Turso client and database helpers
├── templates/         # Jinja2 HTML templates
│   ├── home.html      # Chat interface
│   └── upload.html    # Document upload form
├── static/            # Static assets (JS, CSS, images)
├── .env               # Environment variables
└── README.md          # This document

🚀 Key Technologies

• Python 3.9+
• FastAPI — API routing and async orchestration.
• Aquiles-RAG — Async client for vector indexing and semantic search.
• OpenAI API — text-embedding-3-small for embeddings; gpt-4.1 for answer generation.
• libSQL / Turso.tech — Cloud-hosted SQLite for persisting metadata.
• Jinja2 — Dynamic HTML templating.
• Platformdirs — Locates a user data directory for storing uploads.
• python-dotenv — Loads .env variables.

⚙️ Environment Variables

Create a .env file at the project root with:

# OpenAI
OPENAI_API_KEY=your_openai_api_key

# Aquiles-RAG
URL_RAG=http://localhost:8001     # Your Aquiles-RAG server URL
API_KEY_RAG=your_rag_api_key       # Your Aquiles-RAG API key
INDEX_RAG=docs                     # RAG index name

# Turso / libSQL
URL=your_turso_or_sqlite_url
TOKEN=your_turso_auth_token

📥 Installation & Running

1. Clone the repo

   git clone https://github.com/Aquiles-ai/aquiles-chat-demo.git
   cd aquiles-chat-demo

2. Install dependencies

   pip install -r requirements.txt

3. Initialize the database

   python utils.py   # Creates the `docs` table if it doesn’t exist

4. Start the server

   uvicorn main:app --reload --host 0.0.0.0 --port 5600

5. Access the UI

   • Chat interface → http://localhost:5600/home
   • Upload page → http://localhost:5600/upload

📸 Screenshots

Project UI in action:

Chat interface

Chat interface

Upload form

Upload form

🔍 API Endpoints & WebSocket

1. POST /add-rag

Upload a document and index it in Aquiles-RAG.

• Form Data

  • file (UploadFile): .pdf, .xlsx, .xls, or .docx
  • type_doc (str): "pdf", "excel", or "word"

• Success Response

  { "state": "success" }

• Error Response

  { "error": "detailed error message" }

2. GET /getdocs

Retrieve a list of all indexed documents.

• Response

  {
    "docs": [
      {
        "id": 1,
        "path": "/.../20250806123456_doc.pdf",
        "doc_type": "pdf",
        "created_at": "2025-08-06T12:34:56"
      },
      …
    ]
  }

3. WebSocket /chat

Real-time streaming for RAG + GPT-4.1 responses.

1. Client sends JSON:

   {
     "query": "What is RAG?",
     "top_k": 5
   }

2. Server streams back text chunks as they are generated.

3. Connection closes when answer is complete.

4. HTML Routes

• GET /home → Chat UI
• GET /upload → Document upload form

🛠️ Internal Workflow

1. Indexing (RAGIndexer in context.py):

   • Extract text from PDF/Excel/Word.
   • Generate embeddings.
   • Send chunks to Aquiles-RAG.
   • Store metadata in Turso’s docs table.

2. Query & Response (RAGPipeline in context.py):

   • Optimize the original query into 3–5 concise variants.
   • Fetch top_k chunks per variant from Aquiles-RAG.
   • Merge and sort the highest-scoring chunks.
   • Send context + user query to GPT-4.1 with streaming.

3. Database (utils.py):

   • Manage connections and CRUD operations on Turso (SQLite cloud).

🤖 Usage Example

1. Upload a PDF containing your project documentation.
2. Ask in the chat: “How do I configure FastAPI?”
3. Receive a step-by-step answer, grounded in your PDF content.

📈 Future Improvements

• Deployment: Docker, Vercel, PythonAnywhere.
• Authentication: JWT, OAuth.
• Monitoring Dashboard: Usage metrics & index health.
• Additional Formats: Support TXT, Markdown, HTML.
• User Interface: Allow browsing/upload history and credits.
