UMapx sub-library for encoding and decoding WebP images on Windows

Installation

Install UMapx.Imaging.Webp using NuGet:

dotnet add package UMapx.Imaging.Webp

Quick start

Encode an existing JPEG image and decode the resulting WebP data:

using System.Drawing;
using UMapx.Imaging;

using var bitmap = new Bitmap("input.jpg");
byte[] lossless = bitmap.ToWebp();
byte[] lossy = bitmap.ToWebp(quality: 75, speed: 4);
using var decoded = lossless.FromWebp();

Replace input.jpg with the path to your image. The snippet uses C# 9 or later. The sample project targets .NET 8 for Windows. Run it from the repository root with dotnet run --project examples/UMapx.Imaging.Webp.Example.csproj -c Release. Sample images are copied to its output directory; converted images are written to the results folder beside the executable.

Platform support

The library targets .NET Standard 2.0. It uses System.Drawing and ships native libwebp 1.6.0 for Windows x86 and x64. Native DLLs are included as NuGet runtime assets and selected when the consuming application is built or published. The native builds use the Windows Universal C Runtime and SSE2. Linux, macOS and native ARM64 processes are not supported.

API behavior

Encoding accepts Format24bppRgb and Format32bppArgb bitmaps, with each dimension from 1 to 16383 pixels. Other pixel formats or larger dimensions throw NotSupportedException.

ToWebp() uses lossless compression; RGB values under fully transparent pixels may change. ToWebp(quality, speed) uses lossy color compression, including at quality 100. Both parameters are required: quality ranges from 0 to 100 and also controls alpha-channel compression; alpha values may change below 100. speed ranges from 0 to 9 and controls compression effort, with higher values requesting more effort. Values outside these ranges throw ArgumentOutOfRangeException.

FromWebp() returns a Format32bppArgb bitmap if the WebP image has an alpha channel, or a Format24bppRgb bitmap otherwise. Empty, invalid or incomplete WebP data throws InvalidDataException; animated WebP throws NotSupportedException. Null inputs throw ArgumentNullException.

Only pixel data is converted; EXIF, ICC profiles and other image metadata are not preserved. Dispose decoded bitmaps when finished. Encoding leaves ownership of the input bitmap with the caller. Concurrent encodes must use separate input bitmaps; do not modify input data while a conversion is running.

Build and test

Run the following commands from the repository root on Windows with .NET SDK 8 or later and the .NET 8 x64 runtime installed. Build the solution with dotnet build UMapx.Imaging.Webp.sln -c Release. Run dotnet test UMapx.Imaging.Webp.sln -c Release to execute the xUnit tests against the source project on .NET 8 x64. Tests are also discoverable in Visual Studio. For coverage, run dotnet test UMapx.Imaging.Webp.sln -c Release -p:GeneratePackageOnBuild=false -p:DebugType=portable -p:DebugSymbols=true --collect "XPlat Code Coverage".

Native source download links, checksums and build instructions are recorded in libwebp/README.md, included in the NuGet package.

License

The managed library is MIT licensed. The bundled libwebp and SharpYUV code is covered by the notices in the libwebp/ directory inside the NuGet package.
